Pass Labs XA60.8 Mono Amplifier

Pass Labs XA60.8 Mono Amplifier

Offering all the sonic benefits of the .8 amplifier line, a pair of XA60.8's also grace the listener with mono-block performance: dedicated power supplies for each channel, dedicated circuitry for each channel and dedicated chassis' for each channel offer a cleaner, better defined image and soundstage.

Beautiful to the ears and eyes, this model achieves levels of focus and intimacy normally associated with the finest tube amplifiers. The XA60.8's does all of this while providing greater control and power.

Indication price per pair

View full details
MORE INFORMATION

Designed for audiophiles by even more demanding audiophiles, they invite listeners into the music as never before. Pass Labs uniquely molded each model's front end to the specifics of its output stage so that the amplifiers front ends vary in size, voltage, bias current, dissipation, and singel-ended vs push-pull bias distribution.

The directly coupled front ends, which house the input and voltage gains stages, maximise each model's output stage performance, while imparting to each models its own subtle and unique sonic signature.

These are Pass Laboratories ultimate expression of Power Amplifiers - the perfect blend of science and visceral emotion.

SPECIFICATIONS
Class
A
Type
Mono
Gain (dB)
26
Full Power @ 26 dB gain (V)
1.10
Low Frequency Response
1.5 Hz
High Frequency Response
100 KHz
Power Output /ch (8Ω)
60
Input Impedance (SE & BAL KΩ)
50/100
Damping Factor
150
Power Consumption @ Idle
370 W
Standby Power Consumption
<1 W
Number of Chassis
1
Dimensions
49 x 54 x 19 cm (WxDxH)
Weight
40 kg
