Pass Labs
Pass Labs INT-60 Integrated Amplifier
This integrated amplifier sets a new benchmark in significantly narrowing any perceived performance gap between separate components and integrated amplifiers. Advanced technologies and real-world testing combine to create the INT-60 which presents 60 glorious watts per channel into 8 ohms and doesn't leave class A until 30 watts thanks to its high-bias operation.
This larger Class A operating envelope brings lower distortion and greater loudspeaker control, delivering higher-quality musical fidelity for your enjoyment.
The Bottom Line: Pass Labs’ integrated amplifiers are second to none.
Audiophiles, serious Audiophiles, have not considered an integrated amplifier as worthy product for 30+ years. Pass Labs has changed this paradigm, forever!
- Operational Points optimized for higher wattage requirements
- Greater Versatility
- Stable into any conceivable load
- Spectacular with difficult loads.
The new INT-60 builds on the point 8 series power supply and output stages. It uses the same efficient toroidal design in the power supply with both an electrostatic and Mu-metal shield along with vacuum impregnating and epoxy fi ll. This gives you a very quiet transformer both electrically and mechanically. The power supply circuitry itself is also lower noise and has additional filtering, a little more complicated but worth it.
The INT-60 uses a simplified preamp and volume control circuit that gives you sixty three 1 dB steps with lower noise and distortion while removing some signal path parts.
Overall this makes for a integrated amplifier capable of driving larger less efficient loudspeakers, and being a very good “one-box” solution for a lot of audiophiles.
| Class | : | AB |
| Type | : | Stereo |
| Inputs | : | Four(4) 2 XLR/RCA + 2 RCA |
| Gain | : | 30/36 dB |
| Output Power | : | 60 Watts rms @ 8 Ω |
| : | 120 Watts rms @ 4 Ω | |
| Distortion | : | 1% @ 60 Watts, 8 Ω, 1 KHz |
| Frequency Response | : | -6 dB @ 80 KHz |
| Residual Noise | : | < 250 uV output, unweighted 20 to 20 KHz |
| Damping Factor | : | 150 |
| Input Impedance | : | 45 KΩ |
| Idle Power | : | ~3 Amps @ 120 VAC |
| Remote | : | Yes |
| Power Output / ch (8Ω) | : | 60 |
| Power Consumption | : | 375 W |
| Standby Power Consumption | : | <1 W |
| Dimensions | : | 49 x 56 x 21 cm (WxDxH) |
| Weight | : | 43 Kg |
