Wilson Audio Lōkē Subwoofer

Lōkē Active Subwoofer
LōKē® is an all-in-one, simple to setup, and easy to manage subwoofer solution. Lōkē is Wilson Audio’s smallest subwoofer system to date. This beautiful subwoofer is completely handcrafted by the same artisans and professionals who sculpt all Wilson Audio loudspeakers, made in the United States of America.

Incorporated into LōKē’s built-in amplifier (500 watts) are the most utilized functions from Wilson Audio’s acclaimed ActivXO® Dual Subwoofer Crossover, including such key parameters as crossover frequency, crossover slope, phase, and level.

Loké Active Subwoofer
Wilson Audio Special Application Engineering Introducing Lōkē Wilson Audio’s smallest subwoofer

At the heart of every Wilson Audio® product, you will find designs specifically created to elevate the audio playback experience in your home.

It is precisely this codified North Star approach that led Wilson Audio’s founder, David A. Wilson, to the development of the now legendary WATT® (Wilson Audio Tiny Tot) almost four decades ago. Dave created not only what was to become the upper module of the venerable WATT/Puppy® combo, but also charted the design process now formalized in the Wilson Audio Special Application Engineering® (WASAE) ethos. This brought to life many of our industry leading loudspeaker systems and accessories.

When Wilson Audio began sketching out the modern-day follow-up to the renowned Tiny Tot, it was clear from the outset that TuneTot® would have a similar LF extension profile, a result of limited internal enclosure volume, and would be accompanied one day by a specialized subwoofer system. This compact subwoofer had to complement TuneTot’s application parameters, specifically considering the home environments for which the TuneTot was built. The WASAE team was not satisfied with merely a miniaturization of its core technologies, they wanted to produce a loudspeaker to perform with the timbral beauty, dynamic nuance, soundstage resolution, and transparency in environments which are typically hostile to all these qualities. Today, TuneTot is the cornerstone of many systems found across the globe in spaces not typically conducive to such extraordinary qualities: offices, studies, bedrooms, etc.

Thus, LōKēTM (sounds like “low-key”), Wilson Audio’s smallest and most compact subwoofer system, is an unmistakable extension of the TuneTot eco system. Lōkē not only encompasses full compatibility across the myriad of TuneTot installations, but also fundamentally expands the core capabilities of our other smaller floorstanding loudspeaker models: SabrinaX®, Yvette®, Sasha® DAW, and their predecessors. In short, the WASAE team has not only delivered on the goal of creating a perfect companion to TuneTot, it has delivered a subwoofer system intrinsically designed to enhance and augment all but the largest of our floorstanding loudspeaker models.

Many subwoofer offerings on the market leave the enclosure an underdeveloped aspect of their potential performance envelope. Unfortunately, this leads to the enclosure exhibiting colorations that add unwanted low frequency bloating. As the development of Lōkē solidified, WASAE engineers selected Wilson Audio’s extremely damped X-Material for the external enclosure. A strategic combination of X-Material and HDF comprise the internal bracing support structure ensuring a solid foundation for the woofer coupling. Following the TuneTot’s elegant architectural and sonic elements, Lōkē allows ease of installation and impressive performance while skillfully leaving a remarkably small footprint.

As part of the design approach, the WASAE team took data points from their larger subwoofer systems: Wilson Audio Subsonic®, Thor’s Hammer®, and W.A.T.C.H. Dog®. While these passive and large volume subwoofer systems provide ultimate flexibility and choice of the amplification, LōKē is an all-in-one, simple to setup, and easy to manage subwoofer solution. Incorporated into LōKē’s built-in amp are the most utilized functions from Wilson Audio’s acclaimed ActivXO® Dual Subwoofer Crossover, including such key parameters as crossover frequency, crossover slope, phase, and level. Lastly, proven and refined complex formulas were used to create the custom integrated port to match the carefully selected driver optimized for Wilson’s demanding LF application.

Standard Colors:

  • Galaxy Gray
  • GT Silver
  • Quartz
  • Carbon

 - Upgrade & Pearl Colors on Request.

Wilson Gloss™  Colors

Wilson Audio’s commitment to quality begins with the sound of their loudspeakers, but hardly ends there. The physical beauty and craftsmanship of Wilson products have long set the benchmark for the industry. Now, Wilson Audio is excited to introduce an updated and expanded range of colors, which include new Premium Pearl options.

WilsonGloss is a multi-stage process, from a proprietary protective gel coat layer through base color to the final series of clear coats—all followed by meticulous hand polishing. The final finish is unrivaled—even by the world’s greatest automobile manufacturers. Wilson Audo= have updated the selection of upgrade colors, which are available at a modest surcharge. Wilson Audio Premium WilsonGloss includes five new colors, each in a special pearl finish, which involve additional paint steps. WilsonGloss Premium is the ultimate expression of sophistication and beauty.

When combined with a choice of six grille-cloth colors, it’s easier than ever to individually design your Wilson loudspeaker so that it will complement your décor, or express your pride of ownership. Along with standard black grilles, you can alternatively specify Slate Grey, Parchment Grey, Mocha, Blanco White, or Le Mans Blue at no additional cost. With hundreds and hundreds of combinations available, you have the ability to design a Wilson speaker unique to your taste and décor.

For the ultimate in individual expression, Wilson Audio offers Custom Sample Match WilsonGloss finishes. Through your Wilson Dealer, provide them with your wall color, favourite automotive paint, or just about any color sample and we can, for an additional cost, create your loudspeakers in a one-of-a-kind WilsonGloss finish. This service includes on-site storage of custom paint for a period of five years. Contact your Dealer for program requirements and pricing.

Woofer:One - 25.4 cm
Amplifier Power:500 Watts
Frequency Response:20 Hz to 250 Hz (+/- 1 dB) (Amplifier)
Effective Piston Area:21.75 in²
Effective Displacement:33.42 in³
Height:52.71 cm
Width:35.24 cm
Depth:55.24 cm – with grill
Depth:53.34 cm – without grill
System Weight:49.9 kg


Parameters Test ConditionsTypical Value
Input Sensitivity (L+R):RCA IN 520W/4 Ω @ 115VAC-10dBV
 :XLR IN 500W/4 Ω @ 115VAC-10dBV
Input Sensitivity (L+R):RCA IN Normal input level switch310 mVrms
 :RCA IN Hi-Level input level switch620 mVrms
(Signal in Left and Right):XLR IN Normal input level switch630 mVrms
 :XLR IN Hi-Level input level switch1.25 Vrms
Max Input Level (L+R):RCA IN Normal input level switch1.1  Vrms
 :RCA IN Hi-Level input level switch2.3 Vrms
 :XLR IN Normal input level switch2.4 Vrms
 :XLR IN Hi-Level input level switch4.6 Vrms
Input Impedance:RCA IN10k Ω
 :XLR IN20k Ω
Gain:AMP output 100Hz @ 1W output+43.3 dB (normal)
 : +37.2 dB (Hi- Level IN)
Input Saturation Level:RCA left or right 100Hz>2V (Hi-Level IN)
 :XLR left or right 100Hz>2V (Hi-Level IN)
Noise Level:volume=0dB (MAX)@ A weighted-62.3dBV
S/N Ratio:volume=0dB (MAX)@ A weighted98.4 dB
THD+N Ratio:20-20kHz Filter, Rated Power @100Hz< 1%
Frequency Response:Amplifier output20 Hz to 250 Hz (+/- 1 dB)
Output Power (4Ω):100Hz @ 115VAC, Input: -10dBV (L+R)500 W
Auto ON/OFF:
Auto ON Sensitivity:RCA Left ,100Hz3 mV
Auto OFF Time: 20 mins
Time Delay: 2 ms
Power Amplifier Protection:A- Short-circuit and under load protectionA-Yes
 :B- Thermal protectionB-Yes
 :C-Power Supply Protection-Full Power ProtectionC-Yes
Power Consumption::@ 230Vac/60Hz A- Standby modeA- 0.5 W 0.05 A
 :@ 230Vac/60Hz B- ON modeB- 8.0 W 0.13 A
 :@ 230Vac/60Hz C- 1/8 powerC- 83 W 0.88 A
 :@ 230Vac/60Hz D- 1/4 powerD- 157 W 1.61 A
 :@ 230Vac/60Hz E- Rated powerE- 626 W 5.6 A
 :@ 115Vac/60Hz A- Standby modeA- 0.5 W 0.05 A
 :@ 115Vac/60Hz B- ON modeB- 7.7 W 0.18 A
 :@ 115Vac/60Hz C- 1/8 powerC- 83 W 1.51 A
 :@ 115Vac/60Hz D- 1/4 powerD- 162 W 2.78 A
 :@ 115Vac/60Hz E- Rated powerE- 654 W 9.4 A
